SJE1773-60

PE Cosmetic Bottle 60ml

SJE1773-60

PE Cosmetic Bottle 60ml
PE / HDPE 60 ml
HDPE bottle for travel and discovery sizes, nominal 60 ml, 102 mm tall, 33 x 33 mm base, 5 g empty, 20 mm neck. Existing mold — no tooling; MOQ 5,000 per colour.

Specifications

SKUSJE1773-60
MaterialPE / HDPE
Capacity60 ml
Overflow Capacity64 ml (2.2 fl oz)
Weight5 g
Neck Size20 mm
Total Height102 mm
Shoulder Height93 mm
Base Width33 mm
Base Depth33 mm
MOQ5,000 units
Lead Time15–25 days
CertificationISO 9001 / FDA / SGS
Request Quote →

📦 Download Catalog

Download the complete PE / HDPE bottle catalog PDF.

PE Below 100ml PE 100-200ml PE Above 1000ml

Technical Specifications

Full engineering parameters for SJE1773-60. Nominal factory values — custom colors, printing and finishing available on all parameters below.

Dimensions & Capacity
Nominal Capacity60 ml (2.0 fl oz)
Overflow Capacity (brimful)64 ml (2.2 fl oz)
Bottle Weight5 g
Neck Finish20 mm
Total Height102 mm
Shoulder Height93 mm
Base (W × D)33 × 33 mm
Material & Compliance
MaterialPE/HDPE
Resin GradeFood-contact, virgin (non-recycled)
CertificationsISO 9001 / FDA / SGS
RecyclableYes
Packing & Order Info
Carton PackConfirmed per order — contact us for exact carton specs
MOQ5,000 units
Lead Time15–25 days

Technical Drawing

SJE1773-60 technical dimension drawing
Dimensional drawing of SJE1773-60 — all measurements in millimetres (nominal factory dimensions). For detailed tolerance specs, contact us.

Typical Applications

Typical applications for this small HDPE bottle: travel-size shampoo and conditioner, hand wash, lotion and personal-care samples. Squeezable HDPE is lightweight and drop-safe for travel and retail.

Recommended For

SJE1773-60 is a 60 ml PE / HDPE bottle in the travel & trial size range. It suits sunscreen, opaque lotions, body wash and chemical-sensitive formulations, and is commonly specified for travel-size toiletry, trial kits, hotel amenities and promotional samples. It works with standard screw, pump or flip-top closures to match your filling line.

Closure & Finishing

For branding, silk-screen, hot-stamp and in-mold labeling are available on this PE / HDPE body. Pair it with a screw, pump or flip-top closure to complete a shelf-ready package at a 5,000 units MOQ, produced on ISO 9001 / FDA / SGS certified lines.

Dimensions in working terms

SJE1773-60 is 102 mm tall on a 33 x 33 mm base, so the height is 3.09 times the widest base dimension and the footprint is 10.9 cm².

Total height102 mm
Base (W x D)33 x 33 mm
Footprint10.9 cm²
Height to widest base3.09 : 1
Average content per mm0.59 ml
Empty weight per 100 mm4.90 g
Empty weight per litre held83.3 g
Headspace above nominal4 ml (6.2%)

Closest alternative we already mould

SJT0145-60 is the closest thing we mould to SJE1773-60 at 60 ml: 1 mm taller; 7 g heavier. Moving between the two needs no new tooling.

SKUSJT0145-60
Capacity60 ml (2.0 fl oz)
Height103 mm
Base-
Neck20/410
Weight12 g

Batch yield at a 90% fill line

Stated capacity on SJE1773-60 is 60 ml and the brimful figure is 64 ml, so 4 ml of headspace sits under the rim, inside a body 102 mm tall. Holding the filler at a 90% line puts 54 ml in every unit, so a 500 L batch fills 9,259 of them.

Batch of product60 ml units at 90%Resin for those units
500 L9,25946.3 kg
1,000 L18,51892.6 kg
5,000 L92,592463 kg

Order tiers in real numbers

5,000 units of SJE1773-60 is 300 L of finished product, and 100,000 units is 6,000 L, which takes 500 kg of resin at 5 g a bottle. MOQ is per colour rather than per SKU. 102 mm and 60 ml formats can share one colour. Lead time is 15–30 days from sample sign-off and deposit.

Frequently Asked Questions

Is this PE/HDPE bottle made from food-contact, food-grade material?▼
Yes. ShiJin Package holds a domestic food-production license, and bottles in this range are made from food-contact, virgin (non-recycled) resin — the same material standard as food-contact packaging. Our core production is cosmetic, personal-care and household packaging; the food-contact grade is a material-safety guarantee, not a food-bottle product line.
Can I get this 60ml PE/HDPE bottle with custom color and logo?▼
Yes. 60ml PE/HDPE bottles accept Pantone color matching, silk-screen, hot-stamp or UV printing, labeling, and soft-touch/frosted/metallic finishing. Most projects reuse our existing mold library, so no new tooling cost.
Do you offer samples of SJE1773-60 before bulk ordering?▼
Yes - stock sje1773-60 samples are free (you cover freight). Customized samples with your color or logo carry a small setup fee, refunded on orders above 10,000 units.

Request a quote for SJE1773-60

Tell us your quantity and target market — our engineering team replies within 2 working hours with pricing, lead time and samples. No registration required.

SJE1773-60

ISO 9001 / FDA / SGS certified MOQ 5,000 units Reply within 2 working hours
