PE Cosmetic Bottle 180ml
Download the complete PE / HDPE bottle catalog PDF.
Full engineering parameters for SJE0097-180. Nominal factory values — custom colors, printing and finishing available on all parameters below.
| Dimensions & Capacity | |
| Nominal Capacity | 180 ml (6.1 fl oz) |
| Overflow Capacity (brimful) | 160 ml |
| Bottle Weight | 19 g |
| Neck Finish | 30 mm |
| Total Height | 160 mm |
| Shoulder Height | 112 mm |
| Base (W × D) | 38 × 38 mm |
| Material & Compliance | |
| Material | PE/HDPE |
| Resin Grade | Food-contact, virgin (non-recycled) |
| Certifications | ISO 9001 / FDA / SGS |
| Recyclable | Yes |
| Packing & Order Info | |
| Carton Pack | Confirmed per order — contact us for exact carton specs |
| MOQ | 5,000 units |
| Lead Time | 15–25 days |
Typical applications for this mid-size HDPE bottle: shampoo, conditioner, body wash, hand soap and general personal-care packaging. HDPE resists everyday chemicals and squeezes cleanly to the last drop.
SJE0097-180 is a 180 ml PE / HDPE bottle in the daily face-care size range. It suits sunscreen, opaque lotions, body wash and chemical-sensitive formulations, and is commonly specified for facial serums, essences, toners and daily moisturizers. The 30 mm neck is compatible with standard screw, pump or flip-top closure, so it adapts to pump, spray or screw formats without mold changes.
For branding, silk-screen, hot-stamp and in-mold labeling are available on this PE / HDPE body. Pair it with a matching standard screw, pump or flip-top closure to complete a shelf-ready package at a 5,000 units MOQ, produced on ISO 9001 / FDA / SGS certified lines.
Everything below is calculated from the nominal dimensions in the specification table above (PE / HDPE, 180 ml ≈ 6.1 fl oz, Ø30 mm neck). These figures are engineering guidance for label sizing, closure matching and freight planning — they are not a separate product specification, and final tolerances are confirmed on your approved sample.
| Body geometry | |
| Body shape | Round body — 38 mm diameter across the base, 160 mm tall overall. A round format prints and labels evenly from any angle and reads as a premium cosmetic silhouette. |
| Height to width | 4.21 : 1 (160 mm tall, 38 mm wide). Tall profile: the height carries shelf presence while the carton footprint per unit stays small. |
| Fill-to-outline ratio | 180 ml stated capacity inside a 231 ml rectangular outline — 78 %. A compact envelope relative to the stated capacity — space-efficient in the carton, with less shoulder void. Fill line is normally set at 90–95 % of stated capacity. |
| Unit weight | 19 g body weight = 10.6 g per 100 ml. Mid-weight range: the balance most buyers settle on between hand-feel and freight cost. |
| Label & decoration zone | |
| Usable label height | Up to 107 mm — from the base to the 112 mm shoulder line, less a 5 mm base transition. Taller artwork runs onto the shoulder with a curved-label option. |
| Body circumference | 119 mm (π × 38 mm) — a wrap-around label up to 110 mm wide fits with seam clearance. |
| Recommended maximum label size | ≈ 110 × 107 mm (W × H) wrap label, or a two-panel front/back set on the same circumference. |
| Neck & closure | |
| Neck finish | Ø30 mm screw neck — the 30/410 industry standard, one of the most widely stocked closure sizes worldwide. |
| Dispensing options | lotion pump or wide flip-top cap. |
| Dosing note | At 180 ml the Ø30 mm neck is the standard pairing and is normally run with a single- or double-dose pump. Tell us the dose you need per application (ml per stroke) and we match the pump or sprayer output to it. |
Nearest PE / HDPE formats to this 180 ml model (170 ml, 150 ml, 190 ml, 200 ml), so you can compare a capacity step up or down without leaving the family. Every row is a stocked SKU with its own page and drawings.
| SKU | Capacity | Weight | Neck | Height | Difference |
| SJE0035-200 | 200 ml | 30 g | Ø18 mm | 162 mm | +20 ml larger |
| SJE1867-190 | 190 ml | 20 g | Ø24 mm | 159 mm | +10 ml larger |
| SJE0097-180 | 180 ml | 19 g | Ø30 mm | 160 mm | This model |
| SJE1856-170 | 170 ml | 39 g | Ø24 mm | 169 mm | 10 ml smaller |
| SJE1873-150 | 150 ml | 24 g | Ø20 mm | 95 mm | 30 ml smaller |
Tell us your quantity and target market — our engineering team replies within 2 working hours with pricing, lead time and samples. No registration required.
