PE Cosmetic Bottle 1100ml
Download the complete PE / HDPE bottle catalog PDF.
Full engineering parameters for SJE1668-1100. Nominal factory values — custom colors, printing and finishing available on all parameters below.
| Dimensions & Capacity | |
| Nominal Capacity | 1100 ml (37.2 fl oz) |
| Overflow Capacity (brimful) | 1125 ml (38.0 fl oz) |
| Bottle Weight | 78 g |
| Total Height | 282 mm |
| Shoulder Height | 238 mm |
| Base (W × D) | 104 × 87 mm |
| Material & Compliance | |
| Material | PE/HDPE |
| Resin Grade | Food-contact, virgin (non-recycled) |
| Certifications | ISO 9001 / FDA / SGS |
| Recyclable | Yes |
| Packing & Order Info | |
| Carton Pack | 64 pcs / carton |
| Carton Dimensions (L×W×H) | 76 × 50 × 49 cm |
| MOQ | 5,000 units |
| Lead Time | 15–25 days |
Typical applications for this large HDPE bottle: fabric softener, laundry detergent, household cleaners and high-volume refills. HDPE's chemical resistance and durability make it the standard for household-care packaging.
SJE1668-1100 is a 1100 ml PE / HDPE bottle in the bulk & professional size range. It suits sunscreen, opaque lotions, body wash and chemical-sensitive formulations, and is commonly specified for bulk refill, salon and professional back-bar use. It works with standard screw, pump or flip-top closures to match your filling line.
For branding, silk-screen, hot-stamp and in-mold labeling are available on this PE / HDPE body. Pair it with a screw, pump or flip-top closure to complete a shelf-ready package at a 5,000 units MOQ, produced on ISO 9001 / FDA / SGS certified lines.
Everything below is calculated from the nominal dimensions in the specification table above (PE / HDPE, 1,100 ml ≈ 37.2 fl oz). These figures are engineering guidance for label sizing, closure matching and freight planning — they are not a separate product specification, and final tolerances are confirmed on your approved sample.
| Body geometry | |
| Body shape | Oval body — 104 × 87 mm base (1.20 : 1 width-to-depth). A softer cross-section that sits comfortably in the hand; artwork can run as a wrap or as two facing panels. |
| Height to width | 2.71 : 1 (282 mm tall, 104 mm wide). Tall profile: the height carries shelf presence while the carton footprint per unit stays small. |
| Fill-to-outline ratio | 1,100 ml stated capacity inside a 2,552 ml rectangular outline — 43 %. Generous wall and shoulder clearance — a heavier, more premium feel in hand and more room for a deep shoulder radius. Fill line is normally set at 90–95 % of stated capacity. |
| Unit weight | 78 g body weight = 7.1 g per 100 ml. Lightweight range: lower resin cost per unit and cheaper freight at equal carton count. |
| Label & decoration zone | |
| Usable label height | Up to 233 mm — from the base to the 238 mm shoulder line, less a 5 mm base transition. Taller artwork runs onto the shoulder with a curved-label option. |
| Front panel width | 104 mm flat face → artwork up to 96 mm wide with a 4 mm safety margin each side. |
| Recommended maximum label size | ≈ 96 × 233 mm (W × H) flat label on each face, or a wrap label over the 87 mm sides for tamper evidence. |
Nearest PE / HDPE formats to this 1,100 ml model (1,000 ml, 1,000 ml, 1,200 ml, 1,200 ml), so you can compare a capacity step up or down without leaving the family. Every row is a stocked SKU with its own page and drawings.
| SKU | Capacity | Weight | Neck | Height | Difference |
| SJE1619-1200 | 1,200 ml | 81 g | Ø32 mm | 250 mm | +100 ml larger |
| SJE1680-1200 | 1,200 ml | 94 g | Ø42 mm | 245 mm | +100 ml larger |
| SJE1668-1100 | 1,100 ml | 78 g | Ø— mm | 282 mm | This model |
| SJE1897-1000 | 1,000 ml | 80 g | Ø32 mm | 212 mm | 100 ml smaller |
| SJE1870-1000 | 1,000 ml | 59 g | Ø32 mm | 253 mm | 100 ml smaller |
Tell us your quantity and target market — our engineering team replies within 2 working hours with pricing, lead time and samples. No registration required.
