PE Cosmetic Bottle 30ml
Download the complete PE / HDPE bottle catalog PDF.
Full engineering parameters for SJE1837-30. Nominal factory values — custom colors, printing and finishing available on all parameters below.
| Dimensions & Capacity | |
| Nominal Capacity | 30 ml (1.0 fl oz) |
| Bottle Weight | 8 g |
| Neck Finish | 20 mm |
| Total Height | 89 mm |
| Shoulder Height | 76 mm |
| Base (W × D) | 38 × 24 mm |
| Material & Compliance | |
| Material | PE/HDPE |
| Resin Grade | Food-contact, virgin (non-recycled) |
| Certifications | ISO 9001 / FDA / SGS |
| Recyclable | Yes |
| Packing & Order Info | |
| Carton Pack | Confirmed per order — contact us for exact carton specs |
| MOQ | 5,000 units |
| Lead Time | 15–25 days |
Typical applications for this small HDPE bottle: travel-size shampoo and conditioner, hand wash, lotion and personal-care samples. Squeezable HDPE is lightweight and drop-safe for travel and retail.
SJE1837-30 is a 30 ml PE / HDPE bottle in the travel & sample size range. It suits sunscreen, opaque lotions, body wash and chemical-sensitive formulations, and is commonly specified for travel kits, hotel amenities, free samples and single-use sachets. The 20 mm neck is compatible with a 20/410 lotion pump or disc-top cap, so it adapts to pump, spray or screw formats without mold changes.
For branding, silk-screen, hot-stamp and in-mold labeling are available on this PE / HDPE body. Pair it with a matching a 20/410 lotion pump or disc-top cap to complete a shelf-ready package at a 5,000 units MOQ, produced on ISO 9001 / FDA / SGS certified lines.
Everything below is calculated from the nominal dimensions in the specification table above (PE / HDPE, 30 ml ≈ 1.0 fl oz, Ø20 mm neck). These figures are engineering guidance for label sizing, closure matching and freight planning — they are not a separate product specification, and final tolerances are confirmed on your approved sample.
| Body geometry | |
| Body shape | Flat-oval body — 38 × 24 mm base (1.58 : 1 width-to-depth). Two parallel 38 mm faces carry front and back artwork, while the narrow 24 mm sides suit barcode, batch or ingredient panels. |
| Height to width | 2.34 : 1 (89 mm tall, 38 mm wide). Mid-height format: stable on standard filling and labelling lines without rail changes. |
| Fill-to-outline ratio | 30 ml stated capacity inside a 81 ml rectangular outline — 37 %. Generous wall and shoulder clearance — a heavier, more premium feel in hand and more room for a deep shoulder radius. Fill line is normally set at 90–95 % of stated capacity. |
| Unit weight | 8 g body weight = 26.7 g per 100 ml. Heavy-wall range: chosen when the bottle must feel substantial or survive repeated squeezing. |
| Label & decoration zone | |
| Usable label height | Up to 71 mm — from the base to the 76 mm shoulder line, less a 5 mm base transition. Taller artwork runs onto the shoulder with a curved-label option. |
| Front panel width | 38 mm flat face → artwork up to 30 mm wide with a 4 mm safety margin each side. |
| Recommended maximum label size | ≈ 30 × 71 mm (W × H) flat label on each face, or a wrap label over the 24 mm sides for tamper evidence. |
| Neck & closure | |
| Neck finish | Ø20 mm screw neck — the 20/410 industry standard, one of the most widely stocked closure sizes worldwide. |
| Dispensing options | fine-mist sprayer, treatment pump or disc-top cap. |
| Dosing note | At 30 ml the Ø20 mm neck is the standard pairing and is normally run with a single- or double-dose pump. Tell us the dose you need per application (ml per stroke) and we match the pump or sprayer output to it. |
Nearest PE / HDPE formats to this 30 ml model (15 ml, 12 ml, 45 ml, 50 ml), so you can compare a capacity step up or down without leaving the family. Every row is a stocked SKU with its own page and drawings.
| SKU | Capacity | Weight | Neck | Height | Difference |
| SJE1714-50 | 50 ml | 11 g | Ø20 mm | 98 mm | +20 ml larger · same neck |
| SJE1895-45 | 45 ml | 9 g | Ø20 mm | 71 mm | +15 ml larger · same neck |
| SJE1837-30 | 30 ml | 8 g | Ø20 mm | 89 mm | This model |
| SJE1667-15 | 15 ml | 7 g | Ø16 mm | 126 mm | 15 ml smaller |
| SJE1850-12 | 12 ml | 7 g | Ø16 mm | 91 mm | 18 ml smaller |
Tell us your quantity and target market — our engineering team replies within 2 working hours with pricing, lead time and samples. No registration required.
