PET Cosmetic Bottle 30ml
Download the complete PET bottle catalog PDF for offline viewing.
Full engineering parameters for SJT0201-30. Nominal factory values — custom colors, printing and finishing available on all parameters below.
| Dimensions & Capacity | |
| Nominal Capacity | 30 ml (1.0 fl oz) |
| Overflow Capacity (brimful) | 36 ml (1.2 fl oz) |
| Bottle Weight | 5 g |
| Neck Finish | 20/410 |
| Total Height | 83 mm |
| Shoulder Height | 69 mm |
| Base (W × D) | 32 × 21 mm |
| Material & Compliance | |
| Material | PET |
| Resin Grade | Food-contact, virgin (non-recycled) |
| Certifications | ISO 9001 / FDA / SGS |
| Recyclable | Yes |
| Packing & Order Info | |
| Carton Pack | Confirmed per order — contact us for exact carton specs |
| MOQ | 5,000 units |
| Lead Time | 15–25 days |
Typical applications for this small PET bottle: serums, facial toners, essential-oil blends, hand-sanitizer and travel-size skincare. The clear PET wall shows formula color, and the standard neck pairs with fine-mist sprayers, dropper or screw caps.
SJT0201-30 is a 30 ml PET bottle in the travel & sample size range. It suits clear toners, facial mists, shampoos and lightweight daily-care bottles, and is commonly specified for travel kits, hotel amenities, free samples and single-use sachets. The 20 mm neck is compatible with a 20/410 lotion pump or disc-top cap, so it so it adapts to pump, spray or screw formats without mold changes.
For branding, UV printing, hot-stamp and shrink sleeve are available on this PET body. Pair it with a matching a 20/410 lotion pump or disc-top cap to complete a shelf-ready package at a 5,000 units MOQ, produced on ISO 9001 / FDA / SGS certified lines.
Everything below is calculated from the nominal dimensions in the specification table above (PET, 30 ml ≈ 1.0 fl oz, Ø20 mm neck). These figures are engineering guidance for label sizing, closure matching and freight planning — they are not a separate product specification, and final tolerances are confirmed on your approved sample.
| Body geometry | |
| Body shape | Flat-oval body — 32 × 21 mm base (1.52 : 1 width-to-depth). Two parallel 32 mm faces carry front and back artwork, while the narrow 21 mm sides suit barcode, batch or ingredient panels. |
| Height to width | 2.59 : 1 (83 mm tall, 32 mm wide). Tall profile: the height carries shelf presence while the carton footprint per unit stays small. |
| Fill-to-outline ratio | 30 ml stated capacity inside a 56 ml rectangular outline — 54 %. Typical wall and shoulder allowance for an injection- or extrusion-blown bottle of this size. Fill line is normally set at 90–95 % of stated capacity. |
| Unit weight | 5 g body weight = 16.7 g per 100 ml. Heavy-wall range: chosen when the bottle must feel substantial or survive repeated squeezing. |
| Label & decoration zone | |
| Usable label height | Up to 64 mm — from the base to the 69 mm shoulder line, less a 5 mm base transition. Taller artwork runs onto the shoulder with a curved-label option. |
| Front panel width | 32 mm flat face → artwork up to 24 mm wide with a 4 mm safety margin each side. |
| Recommended maximum label size | ≈ 24 × 64 mm (W × H) flat label on each face, or a wrap label over the 21 mm sides for tamper evidence. |
| Neck & closure | |
| Neck finish | Ø20 mm screw neck — the 20/410 industry standard, one of the most widely stocked closure sizes worldwide. |
| Dispensing options | fine-mist sprayer, treatment pump or disc-top cap. |
| Dosing note | At 30 ml the Ø20 mm neck is the standard pairing and is normally run with a single- or double-dose pump. Tell us the dose you need per application (ml per stroke) and we match the pump or sprayer output to it. |
Nearest PET formats to this 30 ml model (20 ml, 15 ml, 35 ml, 40 ml), so you can compare a capacity step up or down without leaving the family. Every row is a stocked SKU with its own page and drawings.
| SKU | Capacity | Weight | Neck | Height | Difference |
| SJT0034-40 | 40 ml | 5 g | Ø18 mm | 90 mm | +10 ml larger |
| SJT0168-35 | 35 ml | 5 g | Ø20 mm | 101 mm | +5 ml larger · same neck |
| SJT0201-30 | 30 ml | 5 g | Ø20 mm | 83 mm | This model |
| SJT0521-20 | 20 ml | 7 g | Ø18 mm | 65 mm | 10 ml smaller |
| SJT0587-15 | 15 ml | 5 g | Ø18 mm | 69 mm | 15 ml smaller |
